Protocols

Process, Networking and Communication


Valmet offers many innovating valve communication and control products as well as network accessories. Our complete line of Stonel products enable process industry facilities to take advantage of field-based communication technologies to cut installation and maintenance costs and improve operating performance. For over 30 years we have been assisting our customers with network layout/ design, commissioning and troubleshooting of these popular networks.



AS-Interface is considered the ideal protocol for networking discrete automated valves and instruments in the process industries. This easy to install protocol economically networks up to 62 field devices, or 96 with ASi-5 technology, onto a single pair of wires that delivers both signal and power. Interfacing conveniently to most popular PLCs and DCS systems, it may be used in both general purpose and hazardous areas with explosion proofing, nonincendive equipment and nonincendive field wiring protection concepts.
index2

DeviceNet may be used with both discrete and analog applications. It interfaces conveniently into most Rockwell/Allen Bradley and many other DCS/PLC systems integrating up to 63 devices on a 4-wire trunk network carrying power on two wires and communication on the remaining pair. Used in both general purpose and hazardous areas with explosion proofing and nonincendive equipment protection concepts, DeviceNet is suitable for the process industries as well as factory automation.
ff_technology_color_med200px
FOUNDATION Fieldbus has become the de facto standard for networking analog process instrumentation. Designed for use in the process industries, FOUNDATION Fieldbus offers multi-drop capabilities (typically up to 16 devices per network), long trunk length and compatibility with intrinsically safe circuits. Featuring an object oriented block structure for convenient PID loop configuration and true control in the field, FOUNDATION Fieldbus also promises to enhance process performance, reduce set-up time and enable instrument diagnostics.
pblogo170

Available as Profibus DP (Distributed Peripherals) or PA (Process Automation) this protocol has become well accepted for both discrete and analog applications. Profibus DP features High speed data access capable of handling time critical functions while dramatically cutting wiring and commissioning costs. PA is recommended for process applications where intrinsically safe protection concepts must be used.
index5

Traditionally used for integrating I/O back planes into legacy DCS systems, Modbus may be used to network up to 32 analog or discrete devices on a 4-wire network. Because of it’s universal acceptance, this protocol is recommended where legacy systems are prevalent and other protocols may not be readily adapted.
hart_logo_wht_short

HART is widely used in the process industries to monitor and configure analog process instrumentation. Hart has a very strong following and has helped many plants enhance their process performance, by reducing set-up time and enabling instrument diagnostics
