APP Jingui BM2: Moving towards a low-carbon operation
Feb 16, 2023
In 2021, APP Group successfully started up their new Jingui BM2 machine. The Valmet-supplied technology used in BM2 helps the company meet its goals for low-carbon operations. Part of the delivery was an Enzymatic Starch Cooking ZE unit.
The starch cooking system in the CCK workshop adopts the new integrated technology to collect waste heat from the cooking process for heating fresh water. Recycling hot water is in line with our targets for low carbon operations. The integrated design improves our field installation efficiency. It covers a smaller and more compact area than before, and the operation is easy to master.”
Lin Xiupeng, Chief of Paper Chemical Section
Summary
Location
APP Guangxi Jingui Qinzhou, China
Customer target
The unit is part of a solution helping APP reach their goals of low-carbon production, and environmentally efficient and sustainable operation.
Solution
Valmet delivered:
Surface size starch preparation
Binder starch preparation
Capacity range exceeding 120 tn/d (D.S)
It consists of two pre-assembled and pre-tested skid units with patented process solutions for a super-wide capacity range of 20-120 ton per day dry solids. The cooking system offers a fully continuous process with circulation loops resulting in zero wasted starch due to continuous operation even during the normal production stops. It will constantly produce fresh, stable, and high-quality starch. The built-in heat recovery is utilized in integrated hot water preparation resulting in energy savings and decreased load and cost for water treatment.
Results
Heat recovery system:
3500 MWh of heat energy collected per year (verified)
Equals up to 20 tons/steam per day
Savings up to 100,000 €/per unit
Substantially shorter pay pack time for investment
Reduction of 1000 tons of CO2 emissions if fossil fuels are used
Reduction of 400 tons of CO2 emissions if municipal waste is used
Collected energy is used to heat up water at the mill
Starch circulation system:
When in use, starch savings are several tons per month
Keywords
Paper & board, coated white cardboard, FBB, sustainability, improved reliability, China,
Technical data
Grades
Coated white cardboard. Ivory board grades (folding boxboard, FBB) with the basis weight range of 190-330 g/m2.
Technical information
The design speed of the machine is 1,450 m/min and the daily capacity approx. 4,200 tonnes.
