Neles Easyflow™ JT series angle stem tank bottom valves

Flanged floating ball valve for tank bottom applications


Neles Easyflow JT series angle stem tank bottom valves provide a compact assembly with additional space for actuator clearance on insulated vessels. Large port has unobstructed flow to empty or fill the tank quickly. Quarter-turn operation and direct actuator mounting capability makes it easy to automate. Cavity fill and T-port options for the JT series ensure lowest possible dead volume and full draining of media from the valve.

Angle stem tank bottom valves

Features

  • Unique low torque seat design maintains tight shut-off through pressure and temperature
    cycles is standard for valves without cavity fill
  • Enlarged flow port with compact face to face dimensions provides higher flow capacity
  • ISO 5211 mounting pad for direct mounting of handle, gear operator, manual override, or actuator
  • Internal entry blow-out proof stem design
  • An extremely tight fit drive between the stem and ball provides accurate and repeatable shut-off and control
  • Cavity fill option includes solid seats to prevent media being trapped inside the cavity
  • Optional T-port ball provides draining of the cavity between the seats when the valve is closed
  • When combined, cavity fill and T-port ball option provides the best solution to avoid media inside
    the valve
  • Every valve is factory tested, serialised & quality tagged prior to shipment
  • The valve comes with large end flanges for direct mounting with the tank bottom

Benefits

  • Complete package reliability and single source responsibility with Neles full range of actuators, switches, and intelligent valve controllers.
  • Cavity fill and T-port options for the JT series ensure lowest possible dead volume and full draining of media from the valve

Applications

  • Pharmaceutical
  • Biotech
  • Cosmetic
  • Food
  • Chemical

Specifications

Nominal diameter: DN25 – DN150 (NPS 1 – 6)
Pressure rating: Class 150
Flange accommodation: ASME B16.5 Class 150
Face to face dimensions: Manufacturers standard
Vacuum rating: 29.91 inch Hg gauge (759.98 mm Hg gauge or 2x10-2 Torr or 4x10-4 psia or 99.99% vacuum)
Leakage: No visible leakage
Testing: API 598
Standards followed: BS EN 17292, ASME B16.34, API 598, BS EN 12266
Note: The main dimensions of the valve assembly needs to be considered during the installation.
