Neles™ trunnion mounted control valve, series XV

For demanding control applications

a ball valve illustration

Neles™ XV series control valve delivers reliable performance in demanding control applications by combining proven Neles Q-trim™ technology as standard with a compact trunnion-mounted design. The lugged body design offers a compact face-to-face dimension similar to wafer-style valves while enabling safer and more secure installation.

Benefits

Noise and cavitation control as standard

Compact face-to-face design

Secure and reliable installation

Low emissions with live-loaded PTFE packing

Features

Trunnion mounted features

  • Q-trim as standard
  • Non-tight / high-capacity seat
  • Quick operations
  • High cycle capability
  • Reduced bore
  • Maximum Cv per nominal size
  • Equal Percentage flow characteristic

Applications

  • Oil and gas production
  • Natural gas
  • Crude oil
  • Hydrocarbons
  • Liquids, gas and steam
  • Control service

Specifications

Construction Reduced bore trunnion mounted ball valve. Side entry, two-piece bolted body.
Lugged flange connection.
Size range 12”, 16”, 20”, 24”
Face to face

12”- 16” ISA 75.08.02 Table 1
20” and 24” according to manufacturer
Pressure ratings ASME 600
Temperature range -46 °C … +200 °C / -115 °F … +392 °F
