Doctor blades for tissue producers

Comprehensive range of blades for all types of machine positions and processes

Doctor blades and doctor holders-1296x412.jpg

Valmet offers a comprehensive range of doctor blades for all types of process needs in tissue making. The continuous testing of blade materials and development of blades ensures the reliability and high quality of our doctor blades.

Long blade lifetime

More production and fewer machine stoppages

Savings in total production costs

Improved doctoring performance in each position

All kinds of doctor blades for board and paper machines

All our blades are ranged in accordance with their functionality. The Economy range blades are designed to meet today’s quality demands at competitive prices. Doctor blades in the Durability range blades are designed for a maximum blade lifetime. The Performance range includes blades with specific superior features like low friction, high heat resistance and effective cleaning properties.


Economy range - material, features and benefits for cost-efficient blades

BLADE NAME

MATERIAL

FEATURES AND BENEFITS

Valmet Doctor Blade Carbon VT2, 4, 10 Epoxy resin blade (180 C) with 2 or 4 carbon fiber layers or 100%  carbon fibre content Standard doctor blade for most roll cleaning applications
Valmet Doctor Blade Glass Epoxy resin blade (180 C) with glass fibre layers Standard roll cleaning applications
Valmet Doctor Blade Cotton Phenolic resin blade with cotton fibre reinforcement Gentle on roll surfaces
Valmet Doctor Blade Bronze Copper, Phosphor, and tin alloy metal blade Corrosion resistant and good on steel or cast iron rolls
Valmet Doctor Blade Steel Special Carbon Steel Selected rolls in non-corrosive environments



Durability range - material, features and benefits for blades with long lifetime

BLADE NAME

MATERIAL

FEATURES AND BENEFITS

Valmet Doctor Blade Carbon VC2, 4, 10, 10D Epoxy resin blade (180 C) with 2 or 4 carbon fibre layers, or 100% carbon fibre content with functional fillers for durability Blades are designed for maximum blade lifetime
Valmet Doctor Blade Carbon VP12 Long-life Eco resin blade (230 C) with 100% carbon fibre content Blades are designed for maximum blade lifetime
Valmet Doctor Blade Poly D Ultra-High-Density polyethylene blade UHMW-PE Designed for all wet end applications. Gentle on roll covers and lasts long
Valmet Doctor Blade Brite HT Stainless Steel, hardened and tempered Corrosive roll applications
Valmet Doctor Blade Monel K-Monel; Nickel, copper metal blade Corrosive roll applications

Performance range - material, features and benefits for superior results

BLADE NAME

MATERIAL

FEATURES AND BENEFITS

Valmet Doctor Blade Carbon VE2, 4, 10  High heat resistant (230 C) Eco resin blade with 2 or 4 carbon fibre layers, or 100% carbon fibre layers Excellent solution for high-temperature applications
Valmet Doctor Blade Carbon VL10 Epoxy resin blade (180 C) blade with 100% oriented carbon fibre layers Added strength in the MD, and extreme conformability
Valmet Doctor Blade Glass LF Epoxy resin blade (180 C) with glass fibre layers and functional fillers for low friction Low friction cleaning doctor blade
Valmet Doctor Blade Carbon VE T2  High heat resistant (230 C) Eco resin blade with two (2) carbon fibre layers and abrasive particles Abrasive doctor blade used in high-temperature applications
Valmet Doctor Blade Carbon VE T4 High heat resistant (230 C) Eco resin blade with four (4) carbon fibre layers and tending particles Tending doctor blade used in high-temperature applications
Valmet Doctor Blade Glass ABR Fiber glass reinforced epoxy resin blade (180 C) with abrasive particles Recommended for conditioning of dryer surfaces
Valmet Doctor Blade Carbon VC T2 Epoxy resin blade (180 C) with two (2) carbon fibre layers with abrasive particles Long-life abrasive doctor blade
Valmet Doctor Blade Carbon VC T4 Epoxy resin blade (180 C) with four (4) carbon fibre layers with tending particles Long-life tending doctor blade
Valmet Doctor Blade Carbon VE T10 High heat resistant (230 C) Eco resin blade with 100% carbon fibre layers with tending particles Long-life non-epoxy containing tending doctor blade
Valmet Doctor Blade Dual Ultra high-density polyethylene blade UHMW-PE Long-life blade with dual functions - foil and doctor blade
Valmet Doctor Blade Bronze A Extra hard rolled phosphor bronze with ceramic Al203 coating Excellent at stickies removal and will not spark
Valmet Doctot Blade Bronze nCT Extra hard rolled phosphor bronze with WC carbide coating Excellent at stickies removal and will not spark
Valmet Doctor Blade Brite nCT Stainless Steel, cold rolled. WC carbide coated Minimizes sheet wraps and extends blade life
