Class 1 Division 2
Class 1 Division 2
FieldBlock FN
FM (C and US) approved (See certificate for applicable models)
Nonincendive apparatus
Class I Division 2 Groups A,B,C,D
Class II Division 2 Groups E,F,G
Junction Module JX
FM (C and US) approved (See certificate for applicable models)
Nonincendive apparatus
Class I Division 2 Groups A,B,C,D
Class II Division 2 Groups F,G
Junction Module JM
FM (C and US) approved (See certificate for applicable models)
Nonincendive apparatus
Class I Division 2 Groups A,B,C,D
Class II Division 2 Groups F,G
AS- Interface Power supplies
CSA (C and US) approved
Class 1 Division 2 Groups A,B,C,D
| PS459002A | 2.8 Amp AS-Interface Power Supply |
Foundation Fieldbus Power Conditioners
FM and CSA approved to:
Class I Division 2 Groups A,B,C,D
Class II Division 2 Groups E,F,G
| PS459014A | 0.35 Amp Foundation Fieldbus Power Conditioner |
24VDC Power supplies
UL approved to:
Class I Division 2 Groups A,B,C,D
| PS459022A | 3.4 Amp 24VDC High Efficiency Power Supply |
| PS459024A | 5.0 Amp 24VDC High Efficiency Power Supply |
| PS459026A | 10.0 Amp 24VDC High Efficiency Power Supply |
| PS459028A | 10.0 Amp 24VDC Bulk Power Supply |
| PS459032A | 2.1 Amp 24VDC Ultra-Compact Power Supply |
| PS459034A | 4.2 Amp 24VDC Ultra-Compact Power Supply |
| PS459036A | 3.8 Amp 24VDC DeviceNet Power Supply |
| PS459038A | 8.0 Amp 24VDC DeviceNet Power Supply |
FieldLink I/O modules, Repeaters, and Drop Connectors
FM (C and US) approved
Nonincendive apparatus
Class 1 Division 2 Groups A,B,C,D
Class II Division 2 Groups F,G
| Part # | Protocol | Type | Description | Mount |
| IM461050A | AS-Interface | I/O Module | 4DI/4DO | Direct |
| IM465011A | AS-Interface | I/O Module | 4DI/4DO | DIN Rail |
| IM461052A | Foundation Fieldbus | I/O Module | 2DI/2DO | Direct |
| IM465014A | Foundation Fieldbus | I/O Module | 2DI/2DO | DIN Rail |
| IM461054A | Foundation Fieldbus | I/O Module | 2DI/2DO/1AI/1AO | Direct |
| IM465015A | Foundation Fieldbus | I/O Module | 2DI/2DO/1AI/1AO | DIN Rail |
| AC461091A | AS-Interface | Repeater | AS-i Repeater | Direct |
| AC465026A | AS-Interface | Repeater | AS-i Repeater | DIN Rail |
| DR461059A | AS-Interface | Drop Connector | Passive (2) Drop | Direct |
| DR465001A | AS-Interface | Drop Connector | Passive (2) Drop | DIN Rail |
| DR461017A | AS-Interface | Drop Connector | Protected (1) Drop | Direct |
| DR465005A | AS-Interface | Drop Connector | Protected (1) Drop | DIN Rail |
| DR461066A | AS-Interface | Drop Connector | Protected (1) Drop Switch | Direct |
| DR465007A | AS-Interface | Drop Connector | Protected (1) Drop Switch | DIN Rail |
| DR461145A | AS-Interface | Drop Connector | Protected (1) Drop (100mA) | Direct |
| DR465032A | AS-Interface | Drop Connector | Protected (1) Drop (100mA) | DIN Rail |
| DR461146A | AS-Interface | Drop Connector | Protected (1) Drop Switch (100mA) | Direct |
| DR465033A | AS-Interface | Drop Connector | Protected (1) Drop Switch (100mA) | DIN Rail |
FieldLink I/O modules and Drop Connectors
FM (C and US) approved
Nonincendive apparatus
Class 1 Division 2 Groups A,B,C,D
| Part # | Protocol | Type | Description | Mount |
| IO96Y03FA | AS-Interface | I/O Module | 4DI/4DO | Direct |
| IO96W03FA | AS-Interface | I/O Module | 4DI/4DO | Din Rail |
| IO97Y02FA | AS-Interface | I/O Module | 4DI/3DO Ext Addr | Direct |
| IO97W02FA | AS-Interface | I/O Module | 4DI/3DO Ext Addr | Din Rail |
| IO96Y08FA | AS-Interface | I/O Module | 4DI/4DO (2 Relay Out – Independent) | Direct |
| IO96W08FA | AS-Interface | I/O Module | 4DI/4DO (2 Relay Out – Independent) | DIN Rail |
| IO96Y11FA | AS-Interface | I/O Module | 4DI/4DO (2 Relay Out – Interlocking) | Direct |
| IO96W11FA | AS-Interface | I/O Module | 4DI/4DO (2 Relay Out – Interlocking) | DIN Rail |
| IO97Y07FA | AS-Interface | I/O Module | 4DI/3DO (2 Relay Out – Independent) Ext Addr | Direct |
| IO97W07FA | AS-Interface | I/O Module | 4DI/3DO (2 Relay Out – Independent) Ext Addr | DIN Rail |
| IO97Y12FA | AS-Interface | I/O Module | 4DI/3DO (2 Relay Out – Interlocking) Ext Addr | Direct |
| IO97W12FA | AS-Interface | I/O Module | 4DI/3DO (2 Relay Out – Interlocking) Ext Addr | DIN Rail |
| DR465036A | AS-Interface | Drop connector | Passive (6) drop | DIN Rail |
| DR465040A | AS-Interface | Drop connector | Protected (6) drop | DIN Rail |
| DR465044A | AS-Interface | Drop connector | Switched Protected (6) drop | DIN Rail |
| DR465037A | Foundation Fieldbus / Profibus PA |
Drop connector | Passive (6) drop | DIN Rail |
| DR465041A | Foundation Fieldbus / Profibus PA |
Drop connector | Protected (6) drop | DIN Rail |
| DR465045A | Foundation Fieldbus / Profibus PA |
Drop connector | Switched Protected (6) drop | DIN Rail |
| DR465038A | DeviceNet | Drop connector | Passive (6) drop | DIN Rail |
| DR465042A | DeviceNet | Drop connector | Power Protected (6) drop | DIN Rail |
| DR465046A | DeviceNet | Drop connector | Switched / Power Protected (6) drop | DIN Rail |
| DR465039A | Profibus DP / Modbus | Drop connector | Passive (6) drop | DIN Rail |
| DR465043A | Profibus DP/ Modbus | Drop connector | Power Protected (6) drop | DIN Rail |
| DR465047A | Profibus DP / Modbus | Drop connector | Switched / Power Protected (6) drop | DIN Rail |
FieldLink Drop Connectors (NIFW)
FM (C and US) approved
Nonincendive field wiring (NIFW)
Class 1 Division 2 Groups A,B,C,D
Class II Division 2 Groups F,G
| Part # | Protocol | Type | Description | Mount |
| DR461145A | AS-Interface | Drop connector | Protected (1) Drop (100mA) | Direct |
| DR465032A | AS-Interface | Drop connector | Protected (1) Drop (100mA) | DIN Rail |
| DR461146A | AS-Interface | Drop connector | Protected (1) Drop Switch (100mA) | Direct |
| DR465033A | AS-Interface | Drop connector | Protected (1) Drop Switch (100mA) | DIN Rail |
