Liansheng Paper PM5 containerboard machine in China
Valmet's delivery to Liansheng Paper's Longhai site in Fujian province in China included a complete boardmaking line from headbox to reel with air systems, a size supply system, a quality control system and a winder. The two-layer web can be produced with only one headbox providing excellent profiles due to a unique dilution system and good formation due to new type of hydraulics.
"The PM 5 start-up was successful with a stable operating process. The desired targets were achieved. I hope that we can continue a very good cooperation with Valmet also in the future.”
Summary
| Location | Liansheng Paper's Longhai site in Fujian province in China |
| Solution | Valmet's delivery included a complete boardmaking line from headbox to reel with air systems, a size supply system, a quality control system and a winder |
| Results | The PM 5 testliner production line features a novel two-layer forming process with only one hybrid forming unit equipped with the new OptiFlo layering headbox. With this innovative technology a two-layer web can be produced with only one headbox providing excellent profiles due to a unique dilution system and good formation due to new type of hydraulics. |
| Keywords | Paper & board, New lines, China |
Technical data
| Grade | Recycled testliner |
| Basis weight | 100 - 140 g/m2 |
| Wire width | 7250 mm |
| Design speed | 1200 m/min |
| Annual capacity | 350 000 t/a |
