Intuitive design tool for Valmet DNA hardware layout design

Valmet DNA Network Designer

Valmet DNA Network Designer is a tool to design all the layouts of the Valmet DNA: network, fieldbus designs, cabinet and control room layouts etc. Using an easy drag and drop method, users can efficiently design and maintain interactive network pictures. Directly from the pictures, they can connect to the corresponding device to perform maintenance and configuration actions


  • System layouts, control room layouts, cabinet layouts, I/O-labels, connection diagrams Drag-and-drop libraries for all Valmet DNA components
  • Fieldbus design tool and components for PROFINET, Profibus and Ethernet/IP
  • Components including detailed hardware and software information
  • Own component creation
  • Direct connection from drawing to active network component and node
  • Network analysis
  • Excel integration – export and import
  • Part, cable and terminal connection list
  • Snap and glue to shape placeholder
  • Automatic I/O card assembly and I/O labels creation
  • Possibility to generate Valmet DNA Operate diagnostics picture from cabinet layout
  • Analysis of the Ethernet network in system layout based on Microsoft Visio®.


  • Intuitive tool for layouts
  • Detailed product information
  • Efficient tool for Valmet DNA maintenance
  • Excel integration for reporting
